Features
Power Supply
Operating voltage: 21-30V DC, via the EIB bus
Input: 12-48V DC
Output
4 channels: Each channel with two outputs
current: Constant current 350mA/700mA
Load voltage: 3-48V DC
Connections
EIB/KNX: EIB bus connection terminal
Input and output: Screw terminals
Operation and display
Button and Red LED: For assigning the physical address
Green LED flashing: Indicate the application layer running normally
Switch current button for a channel: Set output current for the channel
LED for a channel: Indicate output current of the channel increased by 350mA
