Power Supply

Operation voltage: 21~30V DC, via the EIB bus
Current consumption: <12mA
Power consumption: Max.360mW



Number of contacts: 8
Un rated voltage: 250/440V AC (50/60 HZ)
In rated current: 16A
Max. leakage loss: 2W/4W/8W

Operation and display:

Red LED and push button: For assigning the physical address
Green LED flashing: For display the application layer running normally
Stand-alone operation: Via local operation, extension inputs
