Features
Power Supply
Operation voltage: 21~30V DC , via the EIB bus
Current input: <12mA
Power consumption: <360mW
Outputs
Nominal voltage: 230V AC
Max. switching current: 6A resistive, 370W motor
4 independent output, each with 1 changeover contact (UP/DOWN mechanically interlocked)
Connections
EIB / KNX: Bus connecting terminal(black/red)
Load circuits/230V AC input: Screw terminals
Wire range: 0.2—4.0mm2,Single-core
0.2—2.5mm2,Finely-stranded
Operating and display
UP/DOWN buttons: 2 push buttons per output for UP and DOWN or STOP/Louvre adjustment
